2000 Series Aluminum Alloy Plate

Custom Solution
Guoxin can provide 2000 series, 6000 series and 7000 series aluminum alloy plates and profiles, also provide 1000 series to 7000 series aluminum alloy pipes and rods for customers. Please tell us your needs such as aluminum alloy grade, specifications and heat treatment of this 2000 series aluminum alloy, our company can provide custom aluminum alloy process solutions in client needs.

For more information about aluminum and aluminum alloy grade used in different countries, please click here for reference: Aluminum Grade

Here are Our Recommend Aluminum Alloy Products
2024 Aluminum Alloy Plate
2024 Aluminum Alloy is applied for making aircraft frame, rivet, missile components, truck wheel hub, propeller components, aircraft skin, construction and transport structures, and other structural parts.

Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2024 Aluminum Alloy 0.5 0.5 3.8~4.9 0.3~0.9 1.2~1.8 0.1 0.25 0.15 the rest part
Aluminum Alloy Mechanical and physical properties
tensile strength (25°C) (MPa) yield strength (25°c) (MPa) hardness 500kg 10mm elongation 1.6mm(1/16in) thickness max shear stress (MPa)
2024-T351 470 325 120 10 285
weldability machinability corrosion resistance electricity conductivity 20℃(68℉)
(％IACS) 		density
(20℃) (g/cm3)
limited great poor 30～40 2.78
The Recommend Products also as follows:
Aluminum Alloy Products Applications
2014 Aluminum Alloy Plate 2014 aluminum alloy can be applied for occasions with requirements of high strength, high hardness and high temperature. It can be used as aircraft materials, forgings, thick metal plates and extruded materials, wheels and structural parts, spacecraft parts, the first fuel tank of multistage rocket, truck frame, suspension parts. Inquiry
2219 Aluminum Alloy Plate 2219 aluminum alloy can be applied for oxidizer tank in space racket, supersonic aircraft skin and structural components. The operating temperature of 2219 aluminum alloy is about -270~300℃,it has good welding performance and high fracture toughness. During T8 state, the aluminum alloy has good resistance to stress corrosion cracking. Inquiry
2618 Aluminum Alloy Plate 2618 aluminum alloy can be used for making die forgings and impact forgings, as well as piston and aircraft engine parts. Inquiry
2A50 Aluminum Alloy Plate 2A50 aluminum alloy is used for making complex shaped medium strength spare parts. Inquiry
2A70F Aluminum Alloy Plate 2A70F aluminum alloy is used for making aircraft skin, aircraft engine, pistons, guide wheels, roulette. Inquiry
Guoxin can offer 2000 Series Extruded Aluminum Alloy Plate as follows:
2024 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2024 Aluminum Alloy 0.5 0.5 3.8~4.9 0.3~0.9 1.2~1.8 0.1 0.25 0.15 the rest part
2014 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2014 Aluminum Alloy 0.5~1.2 0.7 3.9~5.0 0.4~1.2 0.2~0.8 0.1 0.25 0.15 the rest part
2219 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2219 Aluminum Alloy 0.2 0.3 5.8~6.8 0.2~0.4 0.2 --- 0.1 0.1~0.25 the rest part
2618 Aluminum Alloy Plate

Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2618 Aluminum Alloy 0.1~0.25 0.9~1.3 1.9~2.7 --- 1.3~1.8 --- 0.1 0.04~0.1 the rest part
2A50 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A50 Aluminum Alloy 0.7~1.2 0.7 1.8~2.6 0.4~0.8 0.4~0.8 --- 0.3 0.15 the rest part
2A70 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A70 Aluminum Alloy 0.35 0.9~1.5 1.9~2.5 0.2 1.4~1.8 --- 0.3 0.02~0.1 the rest part
2011 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2011 Aluminum Alloy 0.4 0.7 5.0~6.0 --- --- --- 0.3 --- the rest part
2017 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2017 Aluminum Alloy 0.2~0.8 0.7 3.5~4.5 0.4~0.1 0.4~0.8 0.1 0.25 0.15 the rest part
2036 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2036 Aluminum Alloy 0.5 0.5 2.2~3.0 0.1~0.4 0.3~0.6 0.1 0.25 0.15 the rest part
2124 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2124 Aluminum Alloy 0.2 0.3 3.8~4.9 0.3~0.9 1.2~1.8 0.1 0.25 0.15 the rest part
2218 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2218 Aluminum Alloy 0.9 1 3.5~4.5 0.2 1.2~1.8 0.1 0.25 --- the rest part
2319 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2319 Aluminum Alloy 0.2 0.3 5.8~6.8 0.2~0.4 0.02 --- 0.1 0.1~0.2 the rest part
2A01 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A01 Aluminum Alloy 0.5 0.5 2.2~3.0 0.2 0.2~0.5 --- 0.1 0.15 the rest part
2A02 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A02 Aluminum Alloy 0.3 0.3 2.3~3.2 0.45~0.7 2~2.4 --- 0.1 0.15 the rest part
2A06 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A06 Aluminum Alloy 0.5 0.5 3.8~4.3 0.5~1.0 1.7~2.3 --- 0.1 0.03~0.15 the rest part
2A10 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A10 Aluminum Alloy 0.25 0.2 3.9~4.5 0.3~0.5 0.15~0.3 --- 0.1 0.15 the rest part
2A11 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A11 Aluminum Alloy 0.7 0.7 3.8~4.8 0.4~0.8 0.4~0.8 --- 0.3 0.15 the rest part
2A14 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A14 Aluminum Alloy 0.6~1.2 0.7 3.9~4.8 0.4~1.0 0.4~0.8 --- 0.3 0.15 the rest part
2A16 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A16 Aluminum Alloy 0.3 0.3 6.0~7.0 0.4~0.8 0.05 --- 0.1 0.1~0.2 the rest part
2A17 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A17 Aluminum Alloy 0.3 0.3 6.0~7.0 0.4~0.8 0.25~0.45 --- 0.1 0.1~0.2 the rest part
2A80 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A80 Aluminum Alloy 0.5~1.2 1.0~1.6 1.9~2.5 0.2 1.4~1.8 --- 0.3 0.15 the rest part
2A90 Aluminum Alloy Plate
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
2A90 Aluminum Alloy 0.5~1.0 0.5~1.0 3.5~4.5 0.2 0.4~0.8 --- 0.3 0.15 the rest part
