6000 Series Aluminum Alloy Pipe

6061-T6 Aluminum Alloy
6082-T6 Aluminum Alloy

Custom Solution
Guoxin manufactures 1000 series to 7000 series aluminum alloy products such as pipes, rods, plates and profiles, please tell us your needs like aluminum alloy grade, specifications and heat treatment of this 6000 series aluminum alloy, our company can provide custom aluminum alloy process solution and products in your needs.

For more information about aluminum and aluminum alloy grade used by different countries, please click here for reference: Aluminum Grade

Our Aluminum Extrusion Press, for making Welded or Seamless Pipes with diameters as follows:
Equipment Products Outer diameter Inner diameter
100MN double-action direct extrusion press welded or seamless alloy pipes 225-507mm 195-435mm
55MN double-action indirect extrusion press welded or seamless alloy pipes 70-265mm 50-254mm
28MN double-action indirect extrusion press welded or seamless alloy pipes 70-137mm 35-125
1880UST double-action direct extrusion press welded or seamless alloy pipes 28-88mm 14-78mm
1100UST double-action direct extrusion press welded or seamless alloy pipes 25-64mm 3-55mm

Recommend Aluminum Alloy Products
6061 Aluminum Alloy Pipe
6061 aluminum alloy is used for making industrial structures with high strength, such as aluminum alloy pipes, bars, plates and profiles for trucks, tower building, ships, light rail vehicle, furniture, machine parts, precision machining, etc.

Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Others Al
6061 Aluminum Alloy 0.40-0.8 0.70 0.15-0.40 0.15 0.8-1.2 0.04-0.35 0.25 0.15 single: 0.05; total: 0.15 the rest part
Alloy Mechanical and physical properties
tensile strength (25°C MPa) yield strength (25°C MPa) hardness 500kg 10mm elongation 1.6mm(1/16in) thickness max shear stress (MPa)
6061-T651 Aluminum Alloy 310 276 95 12 205
weldability machinability corrosion resistance electricity conductivity 20℃(68℉) (％IACS) density
(20℃) (g/cm3)
very good not so bad good 40-50 2.73
The Recommend Products also as follows:
Aluminum Alloy Products Applications
6A02 Aluminum Alloy Pipe 6A02 aluminum alloy is used for making aircraft engine parts, complex shaped forging parts, die forging parts, etc. Inquiry
6082 Aluminum Alloy Pipe 6082 aluminum alloy is used for making high strength and corrosion resistant aluminum alloy products with weldability, such as aviation fixtures, trucks, tower buildings, ships, pipelines. This aluminum alloy can also be used to make aircraft parts, camera lenses, couplers, marine accessories and hardware, electronic fittings and connectors, decorative hardware, hinge head, brake piston, water pistons, electrical appliance accessories, valves and valve parts. Inquiry
Guoxin can offer 6000 Series Aluminum Alloy Pipes as follows: 6061 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6061 Aluminum Alloy 0.4~0.8 0.7 0.15~0.4 0.15 0.8~1.2 0.04~0.35 0.25 0.15 the rest part
6A02 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6A02 Aluminum Alloy 0.5~1.2 0.5 0.2~0.6 0.15~0.35 0.45~0.9 --- 0.2 0.15 the rest part
6082 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6082 Aluminum Alloy 0.7~1.3 0.5 0.1 0.4~1.0 0.6~1.2 0.25 0.2 0.1 the rest part
6005 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6005 Aluminum Alloy 0.6~0.9 0.35 0.1 0.1 0.4~0.6 0.1 0.1 0.1 the rest part
6010 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6010 Aluminum Alloy 0.8~1.2 0.5 0.15~0.6 0.2~0.8 0.6~1 0.1 0.25 0.1 the rest part
6063 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6063 Aluminum Alloy 0.2~0.6 0.35 0.1 0.1 0.45~0.9 0.1 0.1 0.1 the rest part
6066 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6066 Aluminum Alloy 0.9~1.8 0.5 0.7~1.2 0.6~1.1 0.8~1.4 0.4 0.25 0.2 the rest part
6070 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6070 Aluminum Alloy 1.0~1.7 0.5 0.15~0.4 0.4~1.0 0.5~1.2 0.1 0.25 0.15 the rest part
6101 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6101 Aluminum Alloy 0.3~0.7 0.5 0.1 0.03 0.35~0.8 0.03 0.1 --- the rest part
6151 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6151 Aluminum Alloy 0.6~1 1 0.35 0.2 0.45~0.8 0.15~0.35 0.25 0.15 the rest part
6201 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6201 Aluminum Alloy 0.5~0.9 0.5 0.1 0.03 0.6~0.9 0.03 0.1 --- the rest part
6262 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6262 Aluminum Alloy 0.15~0.4 0.4~0.8 0.7 0.15 0.8~1.2 0.04~0.14 0.25 0.15 the rest part
6351 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6351 Aluminum Alloy 0.7~1.3 0.5 0.1 0.4~0.8 0.4~0.8 --- 0.2 0.2 the rest part
6463 Aluminum Alloy Pipe
Alloy Major alloying element (mass fraction) (%)
Si Fe Cu Mn Mg Cr Zn Ti Al
6463 Aluminum Alloy 0.2~0.6 0.15 0.2 0.05 0.45~0.9 --- --- --- the rest part
